Advanced Electrical Installation Work
6th Edition
By Trevor Linsley
Published July 22nd 2011 by Routledge – 212 pages
Description
This textbook covers all the material you need to pass the first part of the new City & Guilds 2357 Diploma in Electrotechnical Technology.
Aligned with the 17th edition IEE Wiring Regulations, this new edition has been thoroughly updated to cover the ‘performance’ section of the latest 2357 course. Written in an accessible style and with a separate chapter for each unit, this book helps you to master each topic before moving on to the next. End of chapter revision questions help you to check your understanding and consolidate the key concepts learned in each chapter. With associated online animations and instructional videos to further support your learning, this is the text that no electrical installations student should be without.
Also available:
Basic Electrical Installation Work 6th edition
Trevor Linsley
ISBN: 9780080966281
Reviews
“Very good book that clearly follows the modular structure of the course”
Martin Amos, Exeter College
"This is a new qualification so these books are the first we have had the opportunity to inspect - as always Trevlor Linsley books are clear and well structured"
Kevin Mincher, Wakefield College
Contents
1 Applying health and safety regulations and working practices
2 Applying environmental legislation and environmental technology systems
3 Organising the work environment
4 Planning, preparing and installing wiring systems
5 Terminating and connecting conductors
6 Inspection, testing and commissioning electrical systems
7 Fault diagnosis and repair
Appendix A: Environmental organisations
Appendix B: Health and Safety Executive (HSE) publications and information
Glossary of terms
Related Subjects
Student Resources
Download these free resources to help you in your studies.
Videos
View all videos in our online playlist, or view them individually:
- Auto RCD Test
- Capacitor Test
- Complete Installation Resistance Values
- Earth Electrode Test
- Earth Fault Loop Impedence Test
- Earth Loop Test
- External Earth Loop Impedence Test
- Generator Rule
- Insulation Resistance Test
- Left Hand Motor Rule
- Prospective Short Circuit Current Test
- R1 + R2 Test
- RCD Ramp Test
- RCD Test
- Ring Circuit Test
- Ring Final Circuit Test
- Safe Isolation Test
- Transformer
- Volt Stick Test
- Voltage Drop Method 1
- Voltage Drop Method 2
Quiz
Flowchart
Animations
Download Quicktime to view the following animation files.
-
The fire triangle
- Electric shock
-
Atoms and electrons on a material
-
Simple AC generator or alternator
-
Simple DC generator or dynamo
-
The first laws of magnetism
-
Magnetic fields around a current carrying conductor
-
MI cable with terminating seal and gland
-
Examples of good and bad posture when using VDU equipment
-
Correct manual lifting and carrying procedure
-
Correct procedure for erecting long or extension ladder
-
Force on a conductor in a magnetic field
-
Metal joining with pop rivets
-
Screw fixing to plastic plug
-
Expansion bolt fixing
-
Spring toggle bolt fixing
-
Farm animal control by electric fence
-
Digital pulse of laser light down an optical fibre cable
-
Output waveforms with smoothing showing reduced ripple with full wave
